MiniVNA PRO BT Antenna analyzer w. Bluetooth

Note: The Software for both versions Mini-VNA and Mini-VNA Pro BT is continously developed. For this reasons a CD ROM is not included in shipment anymore. The current software is always downloadable from the internet.

-Export dat in several formats: JPG, Excel, ZPLOT, S2P, PDF

-Measurements of motional crystal parameters, cable lengths & more

-Integrated Smith Chart in software

-User friendly interface for PC Windows, Linux and MAC

-Boot loader for future firmware upgrades

-extended dynamic range: up to 90dB for transmission, up to 50dB for reflection

-SMA connectors for better isolation

-Power save mode

-Low power consumption, 220mA @3.6V, (analyser mode using USB port)

-Accessory port for future optional interfaces and frequency extenders

-Built in battery charger (up to 400mA)

-Built in LiIon 1000mAh battery, (4 hours full-scan operation)

-Built in Bluetooth® Adaptor (Class 1) for wireless remote measurements

-Two separate RF outputs for I/Q for SDR experiemnts and IMD measurements with independant attenuator from 0 to 55dB, phase angle adjustable to 1° precision

-I/Q DDS Generator with 0 dBm output power

-Two ports VNA with S11 and S12 display; displayed and save results

-Range of impedance Z from 1 to 1000Ω

-Calibration using open/short-load for accurate results

-Frequecy range 0.1 to 200MHz

Further functions and technical data of the mini-VNA Pro BT

The mini-VNA Pro BT is a furthr development of the worldwide highly acclaimed mini-VNA Network Analyser. The most prominent enhancements are a built in LiIon battery and the new Bluetooth interface. Both enhancements allow you to use the mini-VNA Pro BT ouitdoors, directly at the base of the antenna.
